Name: HPE ProLiant DL560 Gen9/10 Servers - P02873-B21
Brand: One Solution Hardware Co

HPE ProLiant DL560 Gen9/10 Servers 5220 2.2GHz Overview

P02873-B21 is the HPE ProLiant DL560 Gen10 6230 2.1GHz 20core 2P 128GB-R P408i-a 8SFF 2x1600W RPS Server. HPE ProLiant DL560 Gen10 server is a high-density, 4P server with high-performance, scalability, and reliability, in a 2U chassis. Supporting the Intel® Xeon® Scalable processors with up to a 61% performance gain, the HPE ProLiant DL560 Gen10 server offers greater processing power,

Table 1 shows the quick spec.

Model	P02873-B21
Description	HPE ProLiant DL560 Gen10 6230 2.1GHz 20core 2P 128GB-R P408i-a 8SFF 2x1600W RPS Server
Processor Name	Intel® Xeon® Scalable 6230 (20 core, 2.1 GHz, 27.5 MB, 125W)
Processor number	2 processors included
Maximum memory	1.5 TB
Memory slots	24 DIMM slots
Memory type	HPE DDR4 SmartMemory
Minimum dimensions (H x W x D)	8.75 x 44.55 x 75.47 cm

HPE DL560 Gen10 8SFF P02873-B21 Specification

P02873-B21 Specification
Model Name	HPE ProLiant DL560 Gen10 6230 2.1GHz 20core 2P 128GB-R P408i-a 8SFF 2x1600W RPS Server
Processor	Intel® Xeon® 6230 (20-Core, 2.1GHz, 125W)
Number of Processors	2
Memory	128 GB
Memory	NOTE: 24 DIMM slots available with Entry Model; 2 more processor slots and 24 more DIMMs available via optional HPE DL5x0 Gen10 CPU Mezzanine Board Kit (872222-B21).
Storage Controller	HPE Smart Array P408i-a
Power Supply	2x 1600W
Power Supply	NOTE: 1600W Power supplies only support high line voltage (200VAC to 240VAC).
PCI-Express Slots	3 PCIe 3.0 slots available NOTE: 8 PCIe 3.0 slots available with the secondary and tertiary riser installed.
Hard drive	None shipped as Standard
Internal Storage	8 SFF Drive Bays NOTE: Can be expanded up to a max of 24 SFF drives, with optional HPE DL560 Gen10 8SFF HDD Bay2 Kit (872235-B21) and HPE DL560 Gen10 8 SFF HDD Bay1 Kit (872231-B21). NOTE: Optionally NVMe SSD drives can be added with HPE DL560 Gen10 Premium 6SFF and 2 NVMe or 8 SFF Bay1 Kit (872227-B21) or HPE DL560 Gen10 Prem 6 SFF+2 NVMe Bay2 Kit(872229-B21) or HPE DL560 Gen10 Premium 6 SFF and 2 NVMe or 8 SFF Bay3 Kit (872231-B21) or HPE DL560 NVMe 8 SSD Express Bay Enablement Kit (872225-B21). NOTE: Alternatively, optional HPE DL560 Gen10 Universal Media Bay Kit.
Optical Drive Bay	Optional via Universal Media Bay
Optical Drive	Optional via Universal Media Bay
Fans	6 hot plug fans, redundant
Management	HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); HPE iLO Advanced and HPE OneView Advanced (require licenses)
Form Factor	RACK (2U), HPE Easy Install Rails with CMA
