Name: HPE Aruba JL678A - Aruba 6100 Series Switch
Brand: One Solution Hardware Co
Rating: 5.00 (1 reviews)

HPE Aruba JL678A Overview

The Aruba CX 6100 Switch Series is modern family of entry level access switches ideal for enterprise branch offices and SMB networks.

Figure 1 shows the appearance of JL678A.

Table 1 shows the Quick Specs.

Figure 2 shows the front panel of JL678A.

Figure 3 shows the back panel of JL678A.

Features

Enterprise-class Layer 2 connectivity with support for ACLs, robust QoS and static routing
Convenient built-in 1/10GbE uplinks and up to 370W of Class 4 PoE for support of IoT devices
Compact and fanless 12 port model for quiet deployment
Manage via single pane of glass with Aruba Central across wired, wireless, and WAN
Automated configuration and verification with Aruba NetEdit
Software defined ready with REST APIs
Simplify adds, moves and changes with colorless ports

Table 2 shows the comparison of JL678A.

JL678A Specification

JL678A specification
Product name	HPE Aruba 6100 24G Switch
Product type	Managed Switch
Connectivity
Ports	24x ports 10/100/1000BASE-T ports 4x 1G/10G SFP ports
Memory and processor	Dual Core ARM Cortex A9 @ 1016 Mhz 4 GB DDR3, maximum, depending on model 16 GB eMMC
Latency	1 Gbps: 1.5 μSec , 10 Gbps: 1.8 μSec
Throughput	95.2 Mpps
Switching capacity	128 Gbps
Performance
Stackable	No
PoE capability	370W, maximum, depending on model
Input voltage	100-127 VAC / 200-240 VAC
Power consumption	Max Power (w/o PoE): 33W
General
Managed	Yes
Ventilation	Fan
Width	17.4 in
Depth	7.9 in
Height	1.7 in
Weight	2.6 kg
Physical properties
Form factor	Rack-mount
Features
Power supply	Internal
